MIETHKE THOMALE GUIDE
Together with the THOMALE GUIDE App for the iPhone and iPad, we provide a precise navigation instrument that prevents incorrect catheter placement. By importing a CT or MRI to the THOMALE GUIDE App the trajectory angle, length of the catheter and distance to the midline can be calculated with a few steps.
The design is based on the principle that in the sagittal plane, a right angle to the surface (tangent) reaches the ventricles correctly, whereas in the coronal plane, an individual angle has to be adjusted in order to allow correct Placement.
